Continuous Peanut Drying Machine Feature
1. The net belt dryer can adjust air quantity, heating temperature, material stay time and feeding speed to obtain the drying effect.
2. The equipment can be equipped with a flexible sclera mechanical mesh belt dryer that can use the network belt flushing system and the material cooling system.
3. The net belt dryer (net belt drier) USES most of the air to recycle and save energy.
4. The unique air splitter of the dryer makes the hot air distribution more uniform and ensures the consistency of the product quality.
5. Heat source can be used with steam, thermal oil or gas stove.
The working principle of
Mesh belt nut dryer is the main principle is to put the material evenly spread in the network, the transmission device drag moving back and forth inside the drying machine, hot air in the materials passing through, the water vapor from the eduction in the platoon is wet hole, so as to achieve the purpose of drying.12-60 mesh belt with steel wire mesh belt, body length is made up by the standard section, in order to save space, the dryer can be made into multi-layer type, there are two common room three, two room five layers, length, 6-40 m, effective width 0.6 3.0 m, mesh belt, transmission device, into the duct, air outlet, fan air (hot are another place), etc.
The linear speed of the net belt depends on the type and moisture content of the material.With negative pressure and porous intake, the air flow is used to ensure the effective drying area. The wind speed is evenly distributed and the drying effect is improved.In order to obtain the drying effect and appropriate yield, the moisture content of the material, the linear speed of the net belt, the air distribution and wind temperature must be properly, reasonably and organically combined.
